Screwdriver bit TiN
HERMAN Pozidriv 50mm
With titanium nitride coating
For screws with Pozidriv (PZ) cross-slot in the screw head, with anti-slip finish, 3 variants
Suitable equipment
Designation
- For series screwdriving with electric and cordless screwdrivers - very long service life even under harsh industrial conditions
- For series screwdriving with impact drivers in harsh industrial environments
Description
Titanium nitride (TiN) applied as a thin coating to the surface of the bit:
an extremely hard ceramic material that multiplies the life and strength of the bit
GPR™ (Grip Point Ribs) anti-slip contact surface:
bit tip with ribbed slots for better screw engagement. Makes it easier to tighten or loosen screws with damaged heads when needed
Flexible TorZon™ torsion zone on the shank reduces pressure on the tip:
the bit behaves like a strong spring when screwing, minimising the possibility of breakage, even under very high torque impacts from impact drivers
Precision-machined bit tip:
fits snugly into the head of the screw, minimising the possibility of damage to the head during screwing
Hardened from tip to shank:
the same properties over the entire length of the bit
Heat treatment optimised for the intended use:
the bit is sufficiently hard and tough for use in standard industrial conditions
Primary material S2 (chromium-silicon-manganese-molybdenum-vanadium steel):
ideal for extremely durable, high-quality bits
With ¼" hexagonal shank (form E 6.3 according to DIN ISO 1173):
for quick-release systems of 1/4" impact screwdrivers as well as for soft screwdriving with a long service life in conjunction with a three-jaw chuck or standard bit holders (form D 6.3 according to DIN ISO 1173)
Surface finish and hardness:
TiN coating /HRC 57~59
