Designation
- Especially for demanding assembly work of a wide range, the possibility of hammer drilling into soft building materials
Comfort
Easy-to-use rotary switch with the possibility of setting 16 tightening torques + 1 position for drilling:
the possibility of choosing a wide range of tightening torques
Separate rotary 2-position switch for turning on the mechanical hammer:
the possibility of hammer drilling in soft building materials
WEIDA all-metal quick-clamping chuck with Auto-Lock function:
reliably, safely and quickly grips the tool in the range of 1.5-13.0 mm
Electronic speed brake:
when the switch is turned off, it immediately stops the rotation of the tool and thus saves time when changing it
Right- and left-hand switching:
the technical solution ensures the same torque in both directions of rotation. The result is the same force when tightening and loosening screws
Continuous speed regulator integrated in the switch:
precise guidance of the drill when drilling holes
LED indicator of the current state of the battery inserted in the tool:
It allows you to continuously check its charge level
Integrated LED for lighting part of the work surface:
more comfortable and precise work
Optimized, ergonomically shaped handle with non-slip rubberized surface:
comfortable, pleasant grip
Flexible battery system for the use of one battery:
all 18,0 V HERMAN batteries, regardless of capacity, are compatible with each other
Metal belt clip:
for fastening the screwdriver to the belt. Demountable if necessary
Light alloy gearbox reduces the weight of the screwdriver
Safety
Right- and left-hand switch closure in intermediate position protects the operator from accidentally turning on the screwdriver
Electronic speed brake:
It immediately stops the rotation of the tool when the switch is turned off. This minimizes the risk of injury to the operator due to the rotation of the tool due to inertia
Lifetime
Overload protection:
intelligent electronics save the motor
Gearbox made of light alloy:
the material used contains additives that increase resistance to wear
Specially shaped air inlets:
They increase the efficiency of engine cooling
Mechanical gear switch:
a reliable speed selection solution with a sliding switch contributes to the long life of the screwdriver
Parameters
| Voltage [V=] | 18,0 |
|---|---|
| Clamping the tool with a quick-clamping chuck - range [mm] | 1,5-13,0 |
| Idle speed 1st stage [U/min] | 0-550 |
| Idle speed 2nd stage [U/min] | 0-2000 |
| Max. torque [Nm] | 60 |
| Accumulator charging cycle cca [min.] | 50 |
| A-weighted emission sound power level (LWA) [dB(A)] | 102 |
| A-weighted emission sound pressure level (LpA) [dB(A)] | 91 |
| Uncertainty (K) [dB(A)] | 3 |
| Weight without battery [kg] | 1,3 |
Contents of the package
- 1x Screwdriver
- 1x Instructions for use
